American Bass DX 10" Car Subwoofer 300 Watts RMS Single Voice Coil 4 Ohm
Many in-stock orders ship within 1-2 business days, but timing varies by item. Custom, built-to-order, oversized, special-order and supplier-direct products may need extra processing time. Free shipping applies to qualifying orders over $99 in the contiguous US. Approved returns may be subject to a restocking fee.
Most products are covered by the manufacturer's warranty against defects. Damage from over-powering or improper installation isn't covered — we'll help coordinate any valid claim.
Tell us your vehicle, subwoofers and electrical setup and our team will help you match the right gear. Reach out before you buy.
Subwoofer Wiring Diagram
Select your configuration to view possible wiring combinations.
Loading wiring diagrams…
Diagrams are on our wiring diagram page.
- 300W RMS / 600W max — tight, punchy everyday bass
- Single 4Ω voice coil — simple plug-and-play wiring
- Compact 10" frame — easy to fit, easy to drive
- 2.0" voice coil — reliable power handling
- Model DX-104 — 90 oz ferrite motor with 12mm Xmax
American Bass DX 10" Car Subwoofer — 300W RMS Single Voice Coil 4Ω (DX-104)
This Listing Includes:
- (1) American Bass DX 10" Subwoofer
The American Bass DX 10" is the compact member of the best-selling DX family — serious punch with zero fuss. The DX Series is the budget-friendly, plug-and-play line optimized for everyday use, and the DX 10" squeezes tight, controlled bass out of a small footprint with a single 4Ω coil that’s easy to wire to any amp. The DX 10" is the smart pick for clean, dependable low end on a budget. Authorized American Bass dealer at JS Ultimate Sounds. Free shipping on orders $99+.
Features
- 2.0" EISV voice coil
- 90 oz ferrite magnet motor
- Paper cone with stitched foam surround
- Heavy-duty metal frame
- Single 4Ω voice coil for easy wiring
- 12mm Xmax for strong excursion
Specifications
| RMS Power | 300W |
| Max Power | 600W |
| Impedance | Single 4Ω |
| Sensitivity | 83.7 dB |
| Voice Coil | 2.0" EISV |
| Magnet | 90 oz ferrite |
| Basket | Heavy-duty metal |
| Cone | Paper, stitched foam surround |
| Mounting Depth | 5.52" |
| Cutout Diameter | 9.24" |
| Fs | 33.6 Hz |
| Qts | 0.49 |
| Qes | 0.53 |
| Qms | 5.89 |
| Vas | 21.6 L |
| Xmax | 12.0 mm |
| BL | 14.1 |
| Mms | 158.3 g |
| Sd | 330 cm² |
| Re | 3.2Ω |
