- Monoblock Class D power: 1600W @ 4Ω, 3400W @ 2Ω, 5000W @ 1Ω RMS
- Purpose-built to drive high-power subwoofer systems down to 1 ohm
- Variable bass boost (0–12dB) and full low/high-pass filtering
- Damping factor of 180 for tight, controlled low-end response
- 450A fuse rating with 4-way protection circuitry
VFL REBEL-5000.1 Class D Monoblock Car Amplifier — 5000W x 1 RMS @ 1Ω (REBEL-5000.1)
This Listing Includes:
- (1) VFL REBEL-5000.1 Monoblock Amplifier
VFL is American Bass's no-compromise competition line, and the REBEL-5000.1 brings that attitude to your subwoofer stage. This Class D monoblock delivers a stable 5000 watts RMS at 1 ohm with the clean, controlled output serious bass builds demand. Authorized American Bass dealer at JS Ultimate Sounds. Free shipping on orders $99+.
Features
- Class D monoblock design optimized for subwoofer duty
- 1-ohm stable for high-output, low-impedance systems
- Variable bass boost, 0dB – 12dB
- Low-pass filter (60Hz–20KHz) and high-pass filter (10Hz–1KHz)
- 4-way protection guards against thermal, voltage, and short faults
Specifications
| Number of Channels | 1 |
| Amplifier Class | Class D |
| RMS Power @ 4Ω | 1600W x 1 |
| RMS Power @ 2Ω | 3400W x 1 |
| RMS Power @ 1Ω | 5000W x 1 |
| Bass Boost | 0dB – 12dB |
| Low-Pass Filter | 60Hz – 20KHz |
| High-Pass Filter | 10Hz – 1KHz |
| Signal-to-Noise Ratio | <92dB |
| THD | <0.1% |
| Damping Factor | 180 |
| Input Sensitivity | 0.4 – 4V |
| Fuse Rating | 450A |
| Dimensions (L x W x H) | 7.05" x 8.66" x 2.24" |
