Trinity Audio Solutions E Series 15" Subwoofer & 1000.1v2 Monoblock Amplifier Package — 1,000W
Many in-stock orders ship within 1-2 business days, but timing varies by item. Custom, built-to-order, oversized, special-order and supplier-direct products may need extra processing time. Free shipping applies to qualifying orders over $99 in the contiguous US. Approved returns may be subject to a restocking fee.
Most products are covered by the manufacturer's warranty against defects. Damage from over-powering or improper installation isn't covered — we'll help coordinate any valid claim.
Tell us your vehicle, subwoofers and electrical setup and our team will help you match the right gear. Reach out before you buy.
A complete, power-matched bass package: the Trinity E Series 15" Subwoofer paired with the Trinity 1000.1v2 Class D Monoblock Amplifier. Built for value-minded bass enthusiasts, the E Series delivers robust everyday bass without demanding a huge electrical investment.
The E Series 15" features a gunmetal stamped basket, a 3" high-temperature dual voice coil, and a double-stacked, FEA-optimized motor structure. Conservatively rated at 800 watts RMS (2,400 watts peak), it performs best in ported, 4th-order, or 6th-order bandpass enclosures. Available from the factory in dual 2-ohm and dual 4-ohm configurations. The compact 1000.1v2 amp includes an oversized heat sink, panel-locking RCA inputs, and a bass knob with volt meter and clip indicator. Backed by a 1-year manufacturer warranty.
Subwoofer Specifications
| Driver | E15 D2 | E15 D4 |
| FS | 27.9 Hz | 29.3 Hz |
| Re | 1.9 Ω + 1.9 Ω | 3.2 Ω + 3.2 Ω |
| Qms | 5.94 | 5.96 |
| Qes | 0.77 | 0.76 |
| Qts | 0.68 | 0.67 |
| Mms | 373.7 | 327.2 |
| Cms | 0.09 | 0.09 |
| Sd | 124.6 in² | 124.6 in² |
| Vas | 76.7 L | 70.1 L |
| SPL | 90.1 dB | 90.6 dB |
| BL | 17.5 | 23.3 |
| X-max | 15mm | 15mm |
| Outer Diameter | 15.35 in | 15.35 in |
| Cutout Diameter | 13.98 in | 13.98 in |
| Motor Diameter | 7.4 in | 7.4 in |
| Mounting Depth | 7.56 in | 7.56 in |
| Displacement | .29 ft³ | .29 ft³ |
| Coil Dimensions | 3" x 40mm | 3" x 40mm |
| Coil Wire | Black Copper | Black Copper |
| Ferrite Grade | Y35 | Y35 |
| Terminal Wire Gauge | 8ga | 8ga |
| RMS Power | 800 | 800 |
| Burst Power | 2,400 | 2,400 |
Amplifier Specifications
| Model | 1000.1v2 |
| RMS @ 4 Ohms | 410 Watts |
| RMS @ 2 Ohms | 680 Watts |
| RMS @ 1 Ohm | 1,000 Watts |
| Total Harmonic Distortion | <.02% |
| Signal to Noise Ratio | 94dB |
| Frequency Range | 10 Hz - 20,000 Hz |
| Signal Input Range | .4 - 7 VAC |
| DC Voltage Input Range | 9-16.5 VDC |
| Dimensions (L x W x H) | 6" x 7.5" x 2.5" |
JS Ultimate Sounds is an authorized Trinity Audio Solutions dealer. Every product is 100% genuine and backed by full manufacturer warranty. Questions about fitment, wiring, or building your system? Our car-audio experts are here to help — reach out any time.
