A complete, power-matched bass package: the Trinity E Series 12" Subwoofer paired with the Trinity 1000.1v2 Class D Monoblock Amplifier. Built for value-minded bass enthusiasts, the E Series delivers robust everyday bass without demanding a huge electrical investment.
The E Series 12" features a gunmetal stamped basket, a 3" high-temperature dual voice coil, and a double-stacked, FEA-optimized motor structure. Rated at 800 watts RMS (2,400 watts peak), it performs best in ported, 4th-order, or 6th-order bandpass enclosures. Available from the factory in dual 2-ohm and dual 4-ohm configurations. The compact 1000.1v2 amp includes an oversized heat sink, panel-locking RCA inputs, and a bass knob with volt meter and clip indicator. Backed by a 1-year manufacturer warranty.
Subwoofer Specifications
| Driver | E12 D2 | E12 D4 |
| FS | 29.6 Hz | 30.9 Hz |
| Re | 1.9 Ω + 1.9 Ω | 3.2 Ω + 3.2 Ω |
| Qms | 6.17 | 5.92 |
| Qes | 0.66 | 0.68 |
| Qts | 0.6 | 0.61 |
| Mms | 306.7 | 259.3 |
| Cms | 0.09 | 0.1 |
| Sd | 77.3 in² | 77.3 in² |
| Vas | 34.4 L | 38.2 L |
| SPL | 88.7 dB | 89.2 dB |
| BL | 17.5 | 21 |
| X-max | 15mm | 15mm |
| Outer Diameter | 12.4 in | 12.4 in |
| Cutout Diameter | 11 in | 11 in |
| Motor Diameter | 7.4 in | 7.4 in |
| Mounting Depth | 6.89 in | 6.89 in |
| Displacement | .20 ft³ | .20 ft³ |
| Coil Dimensions | 3" x 40mm | 3" x 40mm |
| Coil Wire | Black Copper | Black Copper |
| Ferrite Grade | Y35 | Y35 |
| Terminal Wire Gauge | 8ga | 8ga |
| RMS Power | 800 | 800 |
| Burst Power | 2,400 | 2,400 |
Amplifier Specifications
| Model | 1000.1v2 |
| RMS @ 4 Ohms | 410 Watts |
| RMS @ 2 Ohms | 680 Watts |
| RMS @ 1 Ohm | 1,000 Watts |
| Total Harmonic Distortion | <.02% |
| Signal to Noise Ratio | 94dB |
| Frequency Range | 10 Hz - 20,000 Hz |
| Signal Input Range | .4 - 7 VAC |
| DC Voltage Input Range | 9-16.5 VDC |
| Dimensions (L x W x H) | 6" x 7.5" x 2.5" |
