- Power — 150W x 4 @ 4Ω, 225W x 4 @ 2Ω RMS
- Bridged — 450W x 2 @ 4Ω RMS
- Design — Hi-fidelity Class A/B
- Crossovers — Variable 12dB LPF/HPF, 40Hz–5kHz
- Signal-to-Noise — 92dB
This Listing Includes: (1) Sundown Audio SAEv4-150.4 4-Channel Amplifier
The SAEv4-150.4 is a high-fidelity Class A/B four-channel amplifier built on the latest half-bridge technology in a compact form factor. It delivers 150W x 4 at 4 ohms, 225W x 4 at 2 ohms, and 450W x 2 bridged at 4 ohms, with up to 900 watts of output and a 6-volt input sensitivity. An all-new chassis and heatsink with 33% more aluminum keeps it cool during intense sessions, while variable subsonic, high pass, and low pass filters, a 92dB signal-to-noise ratio, and a 4-way protection circuit (thermal, voltage, speaker short, DC offset) keep the output clean and protected. Authorized Sundown Audio dealer at JS Ultimate Sounds. Free shipping on orders $99+.
Features
- Latest half-bridge technology in a compact design
- All-new chassis and heatsink with 33% more aluminum
- Variable crossover slope (LPF/HPF)
- High 92dB signal-to-noise ratio with low noise floor
- Power and protection indicators included
Specifications
| Power @ 4Ω | 150W x 4 |
| Power @ 2Ω | 225W x 4 |
| Bridged @ 4Ω | 450W x 2 |
| Design | Hi-fidelity Class A/B |
| LPF/HPF | Variable 12dB, 40Hz–5kHz |
| Signal-to-Noise Ratio | 92dB |
| Input Sensitivity | 6V |
| Protection | Thermal, voltage, speaker short, DC-offset |
