Orion XTRPRO804D XTR Pro Series 8" 1,000W RMS Subwoofer Dual 4 Ohm
Many in-stock orders ship within 1-2 business days, but timing varies by item. Custom, built-to-order, oversized, special-order, and supplier-direct products may need extra processing time. Free shipping applies to qualifying orders over $99 within the contiguous US. Freight items may require delivery coordination; any shipping exceptions are shown before checkout. Approved returns may be subject to a restocking fee.
Most products are covered by the manufacturer's warranty against defects. Damage from over-powering or improper installation isn't covered — we'll help coordinate any valid claim.
Tell us your vehicle, subwoofers and electrical setup and our team will help you match the right gear. Reach out before you buy.
Subwoofer Wiring Diagram
Select your configuration to view possible wiring combinations.
Loading wiring diagrams…
Diagrams are on our wiring diagram page.
%20with%20a%20dual%204-ohm%20voice%20coil,%20it%20targets%20basshe...
){kind=link}
The Orion XTRPRO804D is an 8-inch competition subwoofer built to move serious air in a compact footprint. Rated at 1,000 watts RMS (4,000 watts peak) with a dual 4-ohm voice coil, it targets bassheads who want SPL-oriented output from a smaller cone and need flexible wiring for their amplifier. Its stiff cone and heavy motor make it a strong choice for a dedicated ported enclosure in a car, truck, or wall build.
Key Features
- 8-inch competition-oriented subwoofer rated at 1,000W RMS / 4,000W peak
- Dual 4-ohm voice coil for versatile wiring (2-ohm or 8-ohm final load per driver)
- 2.5-inch aluminum-wound voice coil on a Kapton former for high-heat durability
- UV-coated reinforced paper cone paired with a rugged Santoprene surround
- Polypropylene dustcap and a large 125 oz ferrite magnet motor
- Forced-convection cooling to help manage heat during extended high-power play
- Compact 6.96-inch mounting depth suits tight cargo and door-off installs
Specifications
| Specification | Value |
|---|---|
| Size | 8 inches |
| RMS Power | 1,000 W |
| Peak Power | 4,000 W |
| Voice Coil Configuration | Dual 4 Ohm |
| Voice Coil Diameter | 2.5 in |
| Voice Coil Material | Aluminum wound on Kapton former |
| Cone Material | UV-coated reinforced paper |
| Surround | Santoprene |
| Dustcap | Polypropylene |
| Magnet | Ferrite, 125 oz |
| Sensitivity | 84.75 dB |
| Frequency Response | 40 Hz – 150 Hz |
| Mounting Depth | 6.96 in (176.8 mm) |
| Cutout Diameter | 8.07 in (202.9 mm) |
| Displacement | 0.06 cu. ft. |
Fitment tip: With a dual 4-ohm coil, a single driver can be wired to a 2-ohm or 8-ohm final load, while pairs open up additional 1-ohm and 4-ohm options at the amplifier. Plan for the 6.96-inch mounting depth and build a properly sized ported box to get the most output from this driver.
