DS18 SELECT S-1600.2 – Select Class AB 2 Channel Full Range Amplifier – 1600 Watts
Powerful Sound in 2 Awesome Colors Red and Silver
The SELECT series of amplifiers by DS18 are known for two things: legendary power and striking elegance. The brushed aluminum comes in red or silver and adds a nice touch of sleekness to your sound system. Each amplifier has adjustable crossover settings, gain control, and Hi/Lo pass filters to deliver powerful and accurate sounds that will make you feel like you’re in a concert!
Order the SELECT S-1600.2 today to own an elegant amplifier that provides awesome power and amazing reliability!
Product Highlights
- Maximum output of 235W x 1CH bridged at 4-Ohms, 90W x 2CH at 4-Ohms, and 130W x 2CH at 2-Ohms
- Surface mount component technology
- Audio precision quality control verification
- Multilayer PCB trace layout
- Clipping, power and protection LED indicator
- Short circuit, thermal and voltage protection
- Precise filters so you can get the perfect sound from your speakers
Technical Details
| Model: | S1600.2 |
| Number Of Channels: | 2 |
| Frequency Response: | 20Hz - 20KHz |
| Max Power: | 1600W |
| RMS Power Output At 2 Ohm | 130W x 2CH |
| RMS Power Output At 4 Ohm | 90W x 2CH |
| RMS Power Output At 4 Ohm Bridged | 235W x 1CH |
| Input Sensitivity: | 0.2-6V |
| Signal-to-Noise Ratio: | >90dB |
| THD: | <0.3% |
| Product Dimensions (L x W x H): | 278x148x47.5(mm) |
