Take Full Command of Your Sound System
The EZY-1216 DSP+ delivers comprehensive audio system control with high-precision digital tuning and outstanding sound clarity. Engineered for professional installers and serious audio enthusiasts, it provides audiophile-grade performance, flexibility, and seamless mobile control.
Inputs
- 12-Channel High/Low-Level Input (High: 28 Vpp; Low: 12 Vpp)
- Bluetooth 5.0 with aptX HD for TRUE high-definition wireless streaming
- RCA, Optical, and Coaxial inputs with limiter
Outputs
- 16-Channel Low-Level Output (12 Vpp)
- Premium Tiffany-Gold RCA jacks
DSP Processing
- 32-bit / 148 MHz DSP processor
- 31-Band EQ with up to 25ms delay per channel
- 96 kHz / 32-bit sampling, 20Hz - 40kHz frequency response
Specifications
| Signal-to-Noise Ratio | >100 dB |
| Total Harmonic Distortion (THD+N) | ≤0.05% |
| Channel Separation | >95 dB |
| Sampling Rate | 96 kHz / 32-Bit |
| Frequency Response | 20Hz - 40kHz |
| Max Input Signal | High 28Vpp / Low 12Vpp |
| Max Output Signal | 12Vpp |
| Working Voltage | DC 9V - 16V |
| Operating Current | 500mA - 1A |
| Operating Temperature | -30°C to 70°C (-22°F to 158°F) |
