Down4Sound DBZ 18" Subwoofer 1300W RMS
Many in-stock orders ship within 1-2 business days, but timing varies by item. Custom, built-to-order, oversized, special-order and supplier-direct products may need extra processing time. Free shipping applies to qualifying orders over $99 in the contiguous US. Approved returns may be subject to a restocking fee.
Most products are covered by the manufacturer's warranty against defects. Damage from over-powering or improper installation isn't covered — we'll help coordinate any valid claim.
Tell us your vehicle, subwoofers and electrical setup and our team will help you match the right gear. Reach out before you buy.
Subwoofer Wiring Diagram
Select your configuration to view possible wiring combinations.
Loading wiring diagrams…
Diagrams are on our wiring diagram page.
The DOWN4SOUND DBz-18 D4 is engineered for listeners who want massive bass output, rugged construction, and unbeatable value. With a true 1300W RMS rating, this 18-inch subwoofer delivers deep, aggressive low-frequency performance suited for daily-driven systems and high-output builds. Featuring a dual 4-ohm voice coil configuration and a real carbon fiber dustcap, the DBz-18 D4 offers wiring flexibility, long-term durability, and powerful bass response.
Key Features
- 1300W RMS power handling
- Dual 4-ohm voice coil design
- 2.75-inch high-temperature voice coil
- 30 mm of Xmax
- Real carbon fiber dustcap
- Advanced motor venting
- Heavy-duty motor structure
Technical Specifications (T/S Parameters)
-
Revc (DC Resistance)
6.050 ohm -
Resonance Frequency (Fs)
30.810 Hz -
Qms
2.745 -
Qes
0.620 -
Qts
0.506 -
Mms (Moving Mass)
481.756 g -
Cms (Compliance)
48.844 μm/N -
Rms
0.780 -
Vas
101.023 L - Sd: 120.887 cm²
-
BL Product
31.152 T·m -
Sensitivity (SPL)
89.5 dB -
Xmax
30 mm -
Displacement
0.21 cu ft
Engineering and Construction
- Extended pole piece
- Rear gap and pole venting
- Long-fiber spider system
- Precision-wound 2.75-inch coil
- Carbon fiber dustcap
Recommended Enclosure
-
Sealed
3.5 cubic feet -
Ported
4.5 cubic feet -
Recommended Tuning
32 Hz -
Recommended Port Area
54 to 68 square inches total
Physical Dimensions
-
Cutout Diameter
16.81 in (427 mm) -
Mounting Depth
9.96 in (253 mm) -
Outside Diameter
18.47 in (469 mm) -
Motor Diameter
16.61 in (422 mm) -
Net Weight
34.2 lb -
Gross Weight
38.5 lb
Why You Should Buy
- Deep, powerful low-frequency performance
- True 1300W RMS output
- Flexible wiring
- Durable construction
- Carbon fiber dustcap
Ideal Applications
- Daily-driven deep-bass systems
- Ported or sealed enclosures in SUVs, trucks, hatchbacks, and sedans
- Systems tuned in 28–35 Hz range
- SQL-style daily builds
- Users seeking high output at an affordable price
