American Bass XR 12" Car Subwoofer 1200 Watts RMS Dual Voice Coil 2 Ohm or 4 Ohm
Many in-stock orders ship within 1-2 business days, but timing varies by item. Custom, built-to-order, oversized, special-order and supplier-direct products may need extra processing time. Free shipping applies to qualifying orders over $99 in the contiguous US. Approved returns may be subject to a restocking fee.
Most products are covered by the manufacturer's warranty against defects. Damage from over-powering or improper installation isn't covered — we'll help coordinate any valid claim.
Tell us your vehicle, subwoofers and electrical setup and our team will help you match the right gear. Reach out before you buy.
Subwoofer Wiring Diagram
Select your configuration to view possible wiring combinations.
Loading wiring diagrams…
Diagrams are on our wiring diagram page.
- 1200W RMS / 2400W Max — clean, hard-hitting 12-inch bass
- Dual 2Ω or dual 4Ω — XR-1222 and XR-1244 for your amp
- 17mm Xmax — long-throw motor for deep output
- Cast frame & stitched rubber surround — durable, good-looking build
- Models XR-1222 / XR-1244 — side-mounted terminals for fast install
American Bass XR 12" Car Subwoofer — 1200W RMS Dual Voice Coil (XR-1222 / XR-1244)
This Listing Includes:
- (1) American Bass XR 12" Subwoofer
The American Bass XR 12" is the easy-to-love power 12 of the XR line. A fiberglass cone, cast frame, and 17mm of Xmax give the XR-1222 and XR-1244 clean, deep bass on 1200 watts RMS. Those redesigned side-mounted terminals make wiring a breeze — drop it in a ported box and feel it move. Authorized American Bass dealer at JS Ultimate Sounds. Free shipping on orders $99+.
Features
- Fiberglass-reinforced cone for stiffness and clean output
- Stitched rubber surround for durable, long-throw excursion
- 3.0" aluminum voice coil for low mass and quick response
- 200 oz magnet for strong motor control
- Cast aluminum frame with side-mounted terminals for easy installation
Specifications
| RMS Power | 1200W |
| Max Power | 2400W |
| Impedance | Dual 2Ω (XR-1222) or Dual 4Ω (XR-1244) |
| Sensitivity | 82.15 dB (XR-1222) / 82.75 dB (XR-1244) |
| Frequency Range | 35 Hz – 500 Hz |
| Voice Coil Diameter | 3.0" |
| Magnet Weight | 200 oz |
| Basket / Frame | Cast |
| Cone Material | Fiberglass |
| Surround | Stitched rubber |
| Mounting Depth | 7.76" |
| Cutout Diameter | 11.61" |
| Fs | 34.2 Hz (XR-1222) / 36.3 Hz (XR-1244) |
| Qts | 0.647 (XR-1222) / 0.747 (XR-1244) |
| Qes | 0.71 (XR-1222) / 0.81 (XR-1244) |
| Qms | 7.32 (XR-1222) / 9.66 (XR-1244) |
| Vas | 18.18 L (XR-1222) / 16.53 L (XR-1244) |
| Xmax | 17 mm |
| BL | 11.95 (XR-1222) / 14.15 (XR-1244) |
| Mms | 475.92 g (XR-1222) / 428.23 g (XR-1244) |
| Sd | 462.1 cm² (XR-1222) / 415.19 cm² (XR-1244) |
| Re | 0.99 Ω (XR-1222) / 1.66 Ω (XR-1244) |
| Le | 0.679 mH (XR-1222) / 0.988 mH (XR-1244) |
