American Bass HD Velocity 12" Car Subwoofer 2200 Watts RMS Dual Voice Coil 1 Ohm or 2 Ohm
Many in-stock orders ship within 1-2 business days, but timing varies by item. Custom, built-to-order, oversized, special-order and supplier-direct products may need extra processing time. Free shipping applies to qualifying orders over $99 in the contiguous US. Approved returns may be subject to a restocking fee.
Most products are covered by the manufacturer's warranty against defects. Damage from over-powering or improper installation isn't covered — we'll help coordinate any valid claim.
Tell us your vehicle, subwoofers and electrical setup and our team will help you match the right gear. Reach out before you buy.
Subwoofer Wiring Diagram
Select your configuration to view possible wiring combinations.
Loading wiring diagrams…
Diagrams are on our wiring diagram page.
%0A%0A3.0%22%204-layer%20high-temp%20coil%20%E2%80%94%20built%20to%20take%20the%20heat%20o...
){kind=link}
- 2200W RMS / 4400W Max — high-output bass for any 12" setup
- Dual 1Ω or Dual 2Ω — match the coil to your amp (VELOCITY-1211 / VELOCITY-1222)
- 3.0" 4-layer high-temp coil — built to take the heat of long sessions
- Triple-stacked 315 oz magnet — efficient motor for clean, deep sound
- Carbon-enhanced cone, blue die-cast basket — 17.5mm Xmax for strong excursion
American Bass HD Velocity 12" Car Subwoofer — 2200W RMS Dual Voice Coil (VELOCITY-1211 / VELOCITY-1222)
This Listing Includes:
- (1) American Bass HD Velocity 12" Subwoofer
Take your car audio to the next level with the American Bass HD Velocity 12". This Velocity Series sub pairs a die-cast basket in a striking blue finish with a carbon-fiber-enhanced cone for clean, deep bass, driven by a 3.0" high-temp voice coil and a triple-stacked 315 oz magnet. Multi-layer poly-cotton spiders keep it precise at 2200W RMS. Choose VELOCITY-1211 for dual 1-ohm or VELOCITY-1222 for dual 2-ohm. Authorized American Bass dealer at JS Ultimate Sounds. Free shipping on orders $99+.
Features
- 3.0" 4-layer high-temperature voice coil
- Triple-stacked 315 oz magnet motor
- Robust die-cast basket with blue finish
- Carbon-fiber-enhanced rigid paper cone with hi & wide 3-layer foam surround
- Dual voice coil with multi-layer poly-cotton spiders and 17.5mm Xmax
Specifications
| RMS Power | 2200W |
| Max Power | 4400W |
| Impedance | Dual 1Ω (1211) / Dual 2Ω (1222) |
| Sensitivity | 85.4 dB (1Ω) / 85.8 dB (2Ω) |
| Voice Coil | 3.0", 4-layer high-temp |
| Magnet | 315 oz, triple-stacked |
| Basket | Die-cast aluminum |
| Mounting Depth | 9.02" |
| Cutout Diameter | 11.34" |
| Xmax | 17.5mm |
| Fs | 32.13 Hz (1Ω) |
| Qts | 0.305 (1Ω) / 0.247 (2Ω) |
| Qes | 0.326 (1Ω) / 0.261 (2Ω) |
| Qms | 4.782 (1Ω) / 4.629 (2Ω) |
| Vas | 21.20 L (1Ω) / 19.27 L (2Ω) |
| BL | 19.52 (1Ω) / 17.12 (2Ω) |
| Mms | 342.1 g (1Ω) / 364.4 g (2Ω) |
| Sd | 46 cm² |
