American Bass Godzilla 12" Car Subwoofer 4700 Watts RMS Dual Voice Coil 1 Ohm or 2 Ohm
Many in-stock orders ship within 1-2 business days, but timing varies by item. Custom, built-to-order, oversized, special-order and supplier-direct products may need extra processing time. Free shipping applies to qualifying orders over $99 in the contiguous US. Approved returns may be subject to a restocking fee.
Most products are covered by the manufacturer's warranty against defects. Damage from over-powering or improper installation isn't covered — we'll help coordinate any valid claim.
Tell us your vehicle, subwoofers and electrical setup and our team will help you match the right gear. Reach out before you buy.
Subwoofer Wiring Diagram
Select your configuration to view possible wiring combinations.
Loading wiring diagrams…
Diagrams are on our wiring diagram page.
%0A%0A3.5%22%20high-temp%20flat-wire%20coil%20%E2%80%94%20built%20to%20survive%20your%20fie...
){kind=link}
- 4700W RMS / 12000W Max — monster power in a 12" chassis
- Dual 1Ω or Dual 2Ω — match the coil to your amp (GODZILLA-1211 / GODZILLA-1222)
- 3.5" high-temp flat-wire coil — built to survive your fiercest tracks
- Triple-stacked 425 oz magnet — oversized motor for a 12-inch driver
- Carbon fiber cone, green die-cast basket — 22.5mm Xmax for big excursion
American Bass Godzilla 12" Car Subwoofer — 4700W RMS Dual Voice Coil (GODZILLA-1211 / GODZILLA-1222)
This Listing Includes:
- (1) American Bass Godzilla 12" Subwoofer
Unleash the beast with the American Bass Godzilla 12". Encased in a green textured die-cast basket with a pure carbon fiber cone, this monster rides a triple-stacked 425 oz magnet and a 3.5" high-temp flat-wire voice coil, built to handle the heat of your fiercest tracks. Double silicone spiders and 4GA copper push terminals keep it precise under serious power. Choose GODZILLA-1211 for dual 1-ohm or GODZILLA-1222 for dual 2-ohm. Authorized American Bass dealer at JS Ultimate Sounds. Free shipping on orders $99+.
Features
- 3.5" high-temperature flat-wire voice coil
- Triple-stacked 425 oz magnet motor
- Green textured die-cast basket
- Carbon fiber cone with carbon foam surround and carbon fiber dust cap
- Dual voice coil with double silicone spiders and 22.5mm Xmax
Specifications
| RMS Power | 4700W |
| Max Power | 12000W |
| Impedance | Dual 1Ω (1211) / Dual 2Ω (1222) |
| Sensitivity | 81.7 dB (1Ω) / 81.0 dB (2Ω) |
| Voice Coil | 3.5", high-temp flat wire |
| Magnet | 425 oz, triple-stacked |
| Basket | Die-cast aluminum |
| Mounting Depth | 9.64" |
| Cutout Diameter | 11.34" |
| Xmax | 22.5mm |
| Fs | 37.0 Hz (1Ω) / 36.72 Hz (2Ω) |
| Qts | 0.43 (1Ω) / 0.45 (2Ω) |
| Qes | 0.46 (1Ω) / 0.49 (2Ω) |
| Qms | 6.79 (1Ω) / 5.19 (2Ω) |
| Vas | 8.7 L (1Ω) / 8.1 L (2Ω) |
| BL | 26.0 (1Ω) / 38.2 (2Ω) |
| Mms | 720.6 g (1Ω) / 788.9 g (2Ω) |
| Sd | 490 cm² |
