American Bass Godfather 3500.1D Class D High Performance Digital Monoblock Amplifier
Many in-stock orders ship within 1-2 business days, but timing varies by item. Custom, built-to-order, oversized, special-order and supplier-direct products may need extra processing time. Free shipping applies to qualifying orders over $99 in the contiguous US. Approved returns may be subject to a restocking fee.
Most products are covered by the manufacturer's warranty against defects. Damage from over-powering or improper installation isn't covered — we'll help coordinate any valid claim.
Tell us your vehicle, subwoofers and electrical setup and our team will help you match the right gear. Reach out before you buy.
Subwoofer Wiring Diagram
Select your configuration to view possible wiring combinations.
Loading wiring diagrams…
Diagrams are on our wiring diagram page.
%20is%20a%20stout%20Class%20D%20monoblock%20for%20high-output%20sub%20stages%0A%0A1%CE%A9%20stable%20Class%20D%20design%20%E2%80%94%20efficient%20power%20down%20to%20a%201-ohm%20load%0A%0A300A%20fuse%20rating%20with...
){kind=link}
- 3047W RMS @ 1Ω — the Godfather 3500.1D (GF-3500.1D) is a stout Class D monoblock for high-output sub stages
- 1Ω stable Class D design — efficient power down to a 1-ohm load
- 300A fuse rating with multi-way protection — guards against DC, short, thermal, and voltage faults
- Variable subsonic + low-pass filters — dial in the exact low-frequency window you need
- 85dB SNR, damping factor <150, <0.1% THD — clean, controlled bass
American Bass Godfather 3500.1D Class D Monoblock Car Amplifier — 3047W RMS (GF-3500.1D)
This Listing Includes:
- (1) American Bass Godfather 3500.1D Amplifier
- (1) Bass Remote Control
The Godfather 3500.1D is a 1-ohm-stable Class D monoblock that delivers 3047 watts RMS, giving you the authority to drive a serious subwoofer stage. This Godfather 3500.1D pairs adjustable subsonic and low-pass filters with 0–9dB of bass boost and multi-way protection, so you get big, clean, tunable low end you stay in control of. Authorized American Bass dealer at JS Ultimate Sounds. Free shipping on orders $99+.
Features
- 1-ohm-stable Class D monoblock for high-output low-frequency power
- Variable subsonic (10Hz–50Hz) and low-pass (35Hz–250Hz) filters
- 0–9dB bass boost at 45Hz with 6V–0.2V input sensitivity
- Multi-way protection circuitry: DC, speaker short, thermal, and voltage
- Damping factor under 150 and <0.1% THD for tight, accurate bass
Specifications
| Channels | 1 |
| Configuration | Class D Monoblock |
| RMS Power @ 4Ω | 1540W |
| RMS Power @ 2Ω | 2280W |
| RMS Power @ 1Ω | 3047W |
| Signal-to-Noise Ratio | 85dB |
| Damping Factor | <150 |
| Input Sensitivity | 6V–0.2V |
| Subsonic Filter | 10Hz–50Hz |
| Low-Pass Filter | 35Hz–250Hz |
| Bass Boost | 0–9dB @ 45Hz |
| THD | <0.1% |
| Fuse Rating | 300A |
| Dimensions (L×W×H) | 13.78 × 7.15 × 2.33 in |
