- 1508W RMS @ 1Ω — the Godfather 1500.1D (GF-1500.1D) is a compact 1-ohm-stable Class D monoblock
- 1Ω stable Class D design — efficient subwoofer power in a small chassis
- 140A fuse rating with multi-way protection — guards against DC, short, thermal, and voltage faults
- Variable subsonic + low-pass filters — tune the exact low-frequency window your subs need
- 85dB SNR, damping factor <150, <0.1% THD — clean, controlled bass
American Bass Godfather 1500.1D Class D Monoblock Car Amplifier — 1508W RMS (GF-1500.1D)
This Listing Includes:
- (1) American Bass Godfather 1500.1D Amplifier
- (1) Bass Remote Control
The Godfather 1500.1D packs 1508 watts RMS at 1 ohm into a compact, 1-ohm-stable Class D chassis that fits where bigger amps won't. This Godfather 1500.1D gives you adjustable subsonic and low-pass filtering, 0–9dB of bass boost, and multi-way protection, so you get clean, controllable low end without giving up space. Authorized American Bass dealer at JS Ultimate Sounds. Free shipping on orders $99+.
Features
- Compact 1-ohm-stable Class D monoblock for efficient subwoofer power
- Variable subsonic (10Hz–50Hz) and low-pass (35Hz–250Hz) filters
- 0–9dB bass boost at 45Hz with 6V–0.2V input sensitivity
- Multi-way protection circuitry: DC, speaker short, thermal, and voltage
- Damping factor under 150 and <0.1% THD for tight, accurate bass
Specifications
| Channels | 1 |
| Configuration | Class D Monoblock |
| RMS Power @ 4Ω | 670W |
| RMS Power @ 2Ω | 1120W |
| RMS Power @ 1Ω | 1508W |
| Signal-to-Noise Ratio | 85dB |
| Damping Factor | <150 |
| Input Sensitivity | 6V–0.2V |
| Subsonic Filter | 10Hz–50Hz |
| Low-Pass Filter | 35Hz–250Hz |
| Bass Boost | 0–9dB @ 45Hz |
| THD | <0.1% |
| Fuse Rating | 140A |
| Dimensions (L×W×H) | 7.09 × 7.15 × 2.33 in |
