DC Audio 9.0K - 9000W RMS Amplifier
Many in-stock orders ship within 1-2 business days, but timing varies by item. Custom, built-to-order, oversized, special-order and supplier-direct products may need extra processing time. Free shipping applies to qualifying orders over $99 in the contiguous US. Approved returns may be subject to a restocking fee.
Most products are covered by the manufacturer's warranty against defects. Damage from over-powering or improper installation isn't covered — we'll help coordinate any valid claim.
Tell us your vehicle, subwoofers and electrical setup and our team will help you match the right gear. Reach out before you buy.
Subwoofer Wiring Diagram
Select your configuration to view possible wiring combinations.
Loading wiring diagrams…
Diagrams are on our wiring diagram page.
The 9.0k competition series amplifier is rated as a 9000 watt mono block. It is a linkable amp and designed to run a 1 ohm per amp or 2 ohms when linked for up to 22,000 watts from a pair. It comes with a bass knob.
Output Power (RMS):
- 2,400x1 @ 4 ohms 14.4 volts
- 4,800x1 @ 2 ohms 14.4 volts
- 9,000x1 @ 1 ohms 14.4 volts
- 18,000x1 @ 2 ohm 14.4 volts LINKED
- 9,800x1 @ 1 ohm 16.0 volts
- 19,600x1 @ 2 ohm 16.0 volts LINKED
- 11,000x1 @ 1 ohm 18.0 volts
- 22,000x1 @ 2 ohm 18.0 volts LINKED
Key Features:
- 1 ohm stable
- Variable low pass filter
- Variable subsonic filter
- Variable bass boost
- RCA Pass Thru
- Linkable
- Wired remote control
- 8awg Speaker Terminals
- Triple 1/0awg Power and Ground Inputs
Full Specs:
| DC Amp Model: | 9.0k |
|---|---|
| Input Sensitivity | 6V~0.2V |
| Frequency Response | 20Hz~250Hz |
| 24dB / Octave Crossover | YES |
| Low Pass | 35Hz ~ 250Hz |
| Subsonic Filter | 10Hz-50hz |
| Bass Boost @45hz | 0 ~ 9db |
| Phase Shift | 0 ~ 180 |
| Remote Control | Yes |
| Clip Indicator | No |
| Signal to Noise Ratio | dB100 |
| Damping Factor | 250< |
| THD @ 4ohms | Less than 0.1% |
| Fuse Rating | External 300 amp x 3 |
| LED Status Lights | Power and Protect |
| Master/Slave | YES |
| Heatsink Length | 34.64"/880mm |
| Heatsink Width | 11.5"/292mm |
| Heatsink Height | 2.6"/66mm |
