DC Audio Level 6 M6 Subwoofer 4500W RMS
Many in-stock orders ship within 1-2 business days, but timing varies by item. Custom, built-to-order, oversized, special-order and supplier-direct products may need extra processing time. Free shipping applies to qualifying orders over $99 in the contiguous US. Approved returns may be subject to a restocking fee.
Most products are covered by the manufacturer's warranty against defects. Damage from over-powering or improper installation isn't covered — we'll help coordinate any valid claim.
Tell us your vehicle, subwoofers and electrical setup and our team will help you match the right gear. Reach out before you buy.
Subwoofer Wiring Diagram
Select your configuration to view possible wiring combinations.
Loading wiring diagrams…
Diagrams are on our wiring diagram page.
- 4500W RMS / 9000W Peak — DC's 4" coil beast for big-power builds
- 4.0" 8-layer flat-wound aluminum coil — wire-cut top plate, extended pole and full inner aluminum sleeve shorting ring
- Dual 10" spaced spiders + extra Xmax clearance — rearward coil clearance for big excursion
- Kraft-pulp fiber-reinforced cone — wide long-throw surround; carbon-fiber cone option available
- Available 12"–18", dual 0.7, 1, 1.4 or 2 ohm — SPL lanes or the cruise strip
This Listing Includes: (1) DC Audio Level 6 M6 Subwoofer
The DC Audio Level 6 M6 Elite is DC's 4" coil beast — a 4,500-watt RMS driver built to keep up with today's biggest amplifiers. A large flat-wound 4" coil, full inner-aluminum-sleeve shorting ring, extended pole and dual 10" spaced spiders give it the power handling and Xmax clearance to crush the lows in the SPL lanes or on the cruise strip. A kraft-pulp reinforced cone and wide long-throw surround handle the excursion, with carbon-fiber cone and dustcap options available; hand-built in the USA. Authorized DC Audio dealer at JS Ultimate Sounds. Free shipping on orders $99+.
Features
- 4.0" 8-layer flat-wound aluminum coil on black-anodized former
- Full inner-aluminum-sleeve shorting ring + extended pole
- Wire-cut top plate with rearward coil clearance
- Dual 10" OD spaced spiders
- Kraft-pulp fiber-reinforced cone, 8 AWG OFC direct leads
Specifications
| RMS Power | 4,500W |
| Peak Power | 9,000W |
| Voice Coil | 4.0" 8-layer flat-wound aluminum |
| Spiders | Dual 10" spaced |
| Cone | Kraft-pulp fiber-reinforced |
| Frame | Cast DC-series aluminum |
| Available Sizes | 12", 15", 18" |
| Impedance | Dual 0.7, 1, 1.4 or 2 Ohm |
| Build | Hand-built USA (7–14 days) |
