Down4Sound SB 8" Subwoofer 500W RMS
Many in-stock orders ship within 1-2 business days, but timing varies by item. Custom, built-to-order, oversized, special-order and supplier-direct products may need extra processing time. Free shipping applies to qualifying orders over $99 in the contiguous US. Approved returns may be subject to a restocking fee.
Most products are covered by the manufacturer's warranty against defects. Damage from over-powering or improper installation isn't covered — we'll help coordinate any valid claim.
Tell us your vehicle, subwoofers and electrical setup and our team will help you match the right gear. Reach out before you buy.
Subwoofer Wiring Diagram
Select your configuration to view possible wiring combinations.
Loading wiring diagrams…
Diagrams are on our wiring diagram page.
Unleash the power of precise bass performance with the DOWN4SOUND SB-8 Subwoofer, crafted for car audio enthusiasts who value clean, impactful sound in a compact footprint. Featuring a dual 2-ohm voice coil configuration and true 500W RMS power handling, this 8-inch subwoofer is optimized for versatile installs, tight spaces, and high-performance daily systems. Engineered with a refined suspension and durable motor structure, the SB-8 D2 delivers reliable, accurate, and punchy bass.
Key Features
- 500W RMS power handling
- Dual 2-ohm voice coil configuration
- 2.5-inch high-temperature voice coil
- 21 mm one-way Xmax
- Highly optimized suspension
- Compact design ideal for tight installations
Technical Specifications (T/S Parameters)
-
Revc (DC Resistance)
3.800 ohm -
Resonance Frequency (Fs)
37.054 Hz -
Qms
3.098 -
Qes
0.582 -
Qts
0.490 -
Mms (Moving Mass)
125.0 g -
Cms (Compliance)
139.651 μm/N -
Rms
Not specified -
Vas
9.016 L - Sd: 210.106 cm²
-
BL Product
14.171 T·m -
Sensitivity (SPL)
80.3 dB -
Xmax
21 mm -
Displacement
0.07 cu ft -
Mounting Depth
4.98 inches
Engineering and Construction
- Optimized suspension for accurate sound reproduction
- Vented motor for cooling efficiency
- Precision-wound 2.5-inch voice coil
- Durable cone and surround assembly
- Compact motor optimized for tight-space performance
